So, you're thinking about installing Coachbuilder shims on your Tundra, huh? Great choice! This upgrade can really improve your truck's stance and performance. But before you dive in, let's get you prepped with a comprehensive guide that covers everything you need to know. We're talking tools, step-by-step instructions, and some handy tips to make the process smooth as butter. Whether you're a seasoned DIYer or a newbie, this guide will walk you through each stage. By the end, you'll not only have a leveled or slightly lifted Tundra but also the satisfaction of knowing you did it yourself. So, grab your tools, and let's get started!

Why Install Coachbuilder Shims on Your Tundra?

Okay, guys, let's talk about why you'd even want to install Coachbuilder shims on your Tundra. There are several reasons, and they're all pretty compelling. First off, many Tundra owners want to eliminate that factory rake – you know, where the rear of the truck sits higher than the front. This isn't just an aesthetic thing; it can affect your truck's handling and appearance, especially when you're hauling or towing. Coachbuilder shims offer a simple, effective way to level out your Tundra, giving it a more balanced and aggressive look. This levels the stance, providing a more aesthetically pleasing and balanced look. Furthermore, by lifting the front, you gain additional clearance, which is great for off-roading or simply navigating uneven terrain. You'll notice an improvement in both on-road handling and off-road capability. Plus, adding a bit of lift allows you to fit larger tires, enhancing both the look and performance of your Tundra. And let's not forget the improved ground clearance, making those pesky parking curbs a little less worrisome. Ultimately, installing Coachbuilder shims is about improving the overall form and function of your Tundra, making it not only look better but also perform better in various driving conditions. It’s a win-win!

Essential Tools and Materials

Alright, before we get our hands dirty, let's make sure you've got all the right tools and materials. Trust me; there's nothing worse than getting halfway through a project and realizing you're missing something crucial. Here’s a comprehensive list to get you started:

• Coachbuilder Shims: Obviously, you'll need the Coachbuilder shims themselves. Make sure you've ordered the correct size for your desired lift. Typically, these come in 1/2 inch, 3/4 inch, and 1-inch sizes.
• Jack and Jack Stands: Safety first! You'll need a reliable jack to lift your Tundra and sturdy jack stands to support it while you work.
• Wheel Chocks: Another safety essential. Use these to secure the rear wheels and prevent any unwanted rolling.
• Socket Set: A comprehensive socket set with various sizes is a must. Make sure it includes metric sizes, as that's what your Tundra uses.
• Wrench Set: Just like the socket set, ensure you have a good variety of metric wrenches.
• Torque Wrench: Absolutely critical for tightening bolts to the correct specifications. Prevents over-tightening and potential damage.
• Hammer: You might need a hammer to gently persuade some parts into place.
• Pry Bar: A pry bar can be helpful for maneuvering suspension components.
• Penetrating Oil: Spray this on any rusty or stubborn bolts to help loosen them up.
• Measuring Tape: For measuring ride height before and after the installation.
• Gloves: Keep your hands clean and protected.
• Safety Glasses: Protect your eyes from debris.
• Optional but Recommended:
  • Impact Wrench: Speeds up the process of removing and tightening bolts.
  • Spring Compressor: If you plan to disassemble the strut assembly, a spring compressor is essential for safety.
  • Alignment After Installation: This will ensure your tires are wearing evenly and your truck handles properly.

Having all these tools and materials on hand will make the installation process much smoother and safer. Take the time to gather everything before you start, and you'll thank yourself later!

Step-by-Step Installation Guide

Okay, let's get down to the nitty-gritty. Here’s a step-by-step guide to installing those Coachbuilder shims on your Tundra. Remember, safety is paramount, so take your time and double-check everything as you go.

1. Preparation:
   • Park your Tundra on a level surface.
   • Engage the parking brake and chock the rear wheels.
   • Gather all your tools and materials.
2. Loosen the Lug Nuts:
   • Use your socket wrench to loosen the lug nuts on the front wheels. Don't remove them completely; just break them free.
3. Lift the Tundra:
   • Position your jack under the front of the Tundra, following the manufacturer's recommended lifting points.
   • Raise the truck until the front wheels are off the ground.
   • Place jack stands securely under the frame rails.
   • Never work under a vehicle supported only by a jack!
4. Remove the Wheels:
   • Finish removing the lug nuts and take off the front wheels.
5. Disconnect the Sway Bar (If Necessary):
   • Some Tundra models may require you to disconnect the sway bar for easier access to the strut assembly.
   • Use your wrench to disconnect the sway bar end links.
6. Remove the Brake Caliper:
   • Unbolt the brake caliper from the spindle.
   • Carefully secure the caliper out of the way, making sure not to strain the brake line. You can use a bungee cord or wire to hang it from the frame.
7. Disconnect the ABS Wire and Brake Line:
   • Carefully disconnect the ABS wire and brake line from their mounting points on the spindle. This will give you more slack and prevent damage to these components.
8. Remove the Strut Assembly:
   • Locate the bolts holding the strut assembly to the lower control arm and the upper mounting points in the engine bay.
   • Use your socket wrench to remove these bolts. You may need to use a hammer and pry bar to help separate the strut assembly from the lower control arm.
   • Be careful when removing the last bolt, as the strut assembly will be free and can drop.
9. Disassemble the Strut (If Required):
   • This step requires a spring compressor and should only be done if you're comfortable with this process.
   • Use the spring compressor to compress the coil spring.
   • Remove the top nut from the strut assembly.
   • Carefully disassemble the strut, noting the orientation of all components.
10. Install the Coachbuilder Shim:
    • Place the Coachbuilder shim on top of the strut mount.
    • If you disassembled the strut, reassemble it in the reverse order, ensuring all components are properly aligned.
    • Tighten the top nut to the manufacturer's specifications.
    • Release the spring compressor.
11. Reinstall the Strut Assembly:
    • Carefully reinstall the strut assembly into the Tundra.
    • Bolt the strut assembly to the lower control arm and the upper mounting points.
    • Tighten all bolts to the manufacturer's specifications using your torque wrench.
12. Reattach the ABS Wire and Brake Line:
    • Securely reattach the ABS wire and brake line to their mounting points on the spindle.
13. Reinstall the Brake Caliper:
    • Reattach the brake caliper to the spindle.
    • Tighten the bolts to the manufacturer's specifications.
14. Reconnect the Sway Bar (If Disconnected):
    • Reconnect the sway bar end links.
    • Tighten the bolts to the manufacturer's specifications.
15. Reinstall the Wheels:
    • Mount the front wheels back onto the Tundra.
    • Hand-tighten the lug nuts.
16. Lower the Tundra:
    • Carefully lower the Tundra until the wheels are on the ground.
    • Remove the jack stands.
17. Torque the Lug Nuts:
    • Use your torque wrench to tighten the lug nuts to the manufacturer's specifications.
18. Repeat on the Other Side:
    • Follow the same steps on the other side of the Tundra.
19. Final Checks:
    • Double-check all bolts and connections to ensure everything is properly tightened.
    • Take the Tundra for a short test drive to check for any unusual noises or vibrations.
20. Get an Alignment:
    • It's highly recommended to get a professional alignment after installing Coachbuilder shims. This will ensure your tires wear evenly and your Tundra handles properly.

Important Notes:

• Always refer to your Tundra's service manual for specific torque specifications and procedures.
• If you're not comfortable with any of these steps, it's best to seek professional assistance.
• Take your time and be careful to avoid damaging any components.

Troubleshooting Common Issues

Even with the best preparation, you might run into a few snags. Here are some common issues and how to tackle them:

• Stubborn Bolts: If you encounter bolts that just won't budge, don't force them. Apply penetrating oil and let it sit for a while. You can also try using a breaker bar for extra leverage. If all else fails, heat can sometimes help, but be careful not to damage surrounding components.
• Strut Assembly Won't Separate: Sometimes, the strut assembly can be difficult to separate from the lower control arm. Use a pry bar to gently persuade it, but be careful not to damage the ball joint or other components. Applying penetrating oil can also help.
• Vibrations After Installation: If you notice vibrations after installing the shims, it could be due to an alignment issue or improperly tightened bolts. Double-check all your connections and get a professional alignment as soon as possible.
• Uneven Lift: If one side of your Tundra sits higher than the other, it could be due to variations in the suspension or an improperly installed shim. Double-check the shim installation and consider consulting a professional if the issue persists.

Maintaining Your Tundra After Shim Installation

Once you've got those Coachbuilder shims installed, it's important to keep your Tundra in tip-top shape. Here’s how:

• Regular Inspections: Periodically inspect the suspension components, including the shims, struts, and control arms, for any signs of wear or damage. Look for loose bolts, cracks, or excessive rust.
• Alignment Checks: Get your Tundra aligned at least once a year, or more often if you notice any signs of misalignment, such as uneven tire wear or pulling to one side.
• Tire Rotations: Rotate your tires regularly to ensure even wear. This will extend the life of your tires and improve your Tundra's handling.
• Proper Torque: Always use a torque wrench when tightening bolts on the suspension components. This will prevent over-tightening and potential damage.
• Cleanliness: Keep the suspension components clean to prevent rust and corrosion. Wash your Tundra regularly, especially after driving in harsh conditions.

Conclusion

Alright, there you have it – a comprehensive guide to installing Coachbuilder shims on your Tundra. By following these steps and taking your time, you can achieve a leveled or slightly lifted stance that not only looks great but also improves your truck's performance. Remember, safety is always the top priority, so don't hesitate to seek professional assistance if you're not comfortable with any of the steps. Happy wrenching, and enjoy your newly upgraded Tundra!
