FortiGate SSL VPN: Connect With OpenVPN Client

Let's dive into setting up a FortiGate SSL VPN to work seamlessly with an OpenVPN client. This setup allows users to securely connect to your network using the widely-supported OpenVPN protocol. This guide will walk you through the necessary steps to configure your FortiGate firewall and OpenVPN client for a successful connection. It's like building a secure tunnel straight into your network, ensuring that your data stays safe and sound, no matter where you're connecting from.

Understanding the Basics

Before we jump into the configuration, let's clarify what each component does:

FortiGate: Think of this as the gatekeeper of your network. It's a firewall that controls who gets in and out, and it can also act as a VPN server.
SSL VPN: This is a type of VPN that uses SSL/TLS encryption to secure the connection. It's like wrapping your data in a super-strong digital shield.
OpenVPN Client: This is the software you install on your device (computer, smartphone, etc.) to connect to the VPN server. It's the key that unlocks the secure tunnel.

Knowing these basics is super important, guys, because it helps you understand why we're doing each step. No more blindly following instructions! You'll actually get it.

Configuring FortiGate for SSL VPN

First, we need to configure the FortiGate to act as an SSL VPN server. Here's how you do it:

Step 1: Enable SSL VPN

Log in to your FortiGate's web interface. This is usually done by typing the FortiGate's IP address into your web browser.
Go to VPN > SSL-VPN Settings. Here, you'll find all the settings related to SSL VPN.
Enable the SSL VPN. This is usually a simple checkbox or toggle switch. Make sure it's turned on!

Step 2: Configure IP Pools

IP pools are like a range of IP addresses that the FortiGate will assign to VPN clients when they connect. You need to define these.

Go to User & Authentication > IP Pools and click Create New.
Give the IP pool a name (e.g., "VPN_IP_Pool").
Enter the starting and ending IP addresses for the pool. Make sure these IPs are within your network's range but not in use by any other devices. For example, you might use 192.168.200.100 to 192.168.200.200.
Set the Netmask to match your network (usually 255.255.255.0).
Click OK to save the IP pool.

Step 3: Create a User Group

User groups help you manage which users have access to the VPN. It's like creating a VIP club for VPN access.

Go to User & Authentication > User Groups and click Create New.
Give the group a name (e.g., "VPN_Users").
Add the users who should have VPN access to this group. If you don't have any users yet, you'll need to create them under User & Authentication > Users first.
Click OK to save the user group.

Step 4: Configure SSL VPN Portal

The SSL VPN portal is where you define the settings for the VPN connection, such as the IP pool to use and the user group that has access.

Go to VPN > SSL-VPN Portals and click Create New.
Give the portal a name (e.g., "OpenVPN_Portal").
Under Tunnel Mode, configure the following:
- IP Pools: Select the IP pool you created earlier (e.g., "VPN_IP_Pool").
- Source IP Filters: Leave this blank unless you need to restrict access based on source IP.
- Source Netmask: Leave this blank unless you're using source IP filters.
Under Authentication, select the user group you created earlier (e.g., "VPN_Users").
Under Split Tunneling, you can choose whether to route all traffic through the VPN or only traffic destined for your internal network. If you want all traffic to go through the VPN, disable split tunneling. If you only want traffic for your internal network to go through the VPN, enable it and specify the destinations.
Click OK to save the portal.

Step 5: Create a Firewall Policy

Finally, you need to create a firewall policy to allow traffic from the VPN to your internal network.

Go to Policy & Objects > Firewall Policy and click Create New.
Configure the following:
- Name: Give the policy a name (e.g., "VPN_to_Internal").
- Incoming Interface: Select the SSL VPN interface (usually ssl.root).
- Outgoing Interface: Select the interface connected to your internal network (e.g., internal).
- Source Address: Select the IP pool you created earlier (e.g., "VPN_IP_Pool").
- Destination Address: Select the internal network you want to allow access to (e.g., 192.168.1.0/24).
- Schedule: Set this to always.
- Service: Set this to ALL or specify the services you want to allow (e.g., HTTP, HTTPS, SSH).
- Action: Set this to ACCEPT.
- Enable NAT: Disable this.
- Log Allowed Traffic: Enable this for auditing purposes.
Click OK to save the firewall policy.

Configuring the OpenVPN Client

Now that the FortiGate is set up, let's configure the OpenVPN client.

| Read Also : Ubur-Ubur, Ikan Lele & Kena Tilang: Kisah Lucu Yang Bikin Ngakak!

Step 1: Download and Install OpenVPN Client

Download the OpenVPN client from the official OpenVPN website and install it on your device.

Step 2: Obtain the FortiGate SSL VPN Configuration File

To connect the OpenVPN client to the FortiGate SSL VPN, you need a configuration file. There are a couple of ways to get this:

Download from FortiGate Web Portal:
- Log in to the FortiGate web portal using a web browser. The URL is typically https://<FortiGate IP address>:<SSL VPN port number>. The default port number is 443.
- Authenticate with a user that is a member of the VPN user group.
- Download the OpenVPN configuration file from the portal. It's usually a .ovpn file.
Manually Create the Configuration File:

If you can't download the configuration file, you can create one manually. Here's an example of what the configuration file should look like:

client
dev tun
proto tcp
remote <FortiGate IP address> <SSL VPN port number>
resolv-retry infinite
nobind
persist-key
persist-tun
ca fortigate-ca.crt
cert client.crt
key client.key
remote-cert-tls server
comp-lzo
verb 3

Replace <FortiGate IP address> and <SSL VPN port number> with the actual IP address and port number of your FortiGate. You'll also need to obtain the fortigate-ca.crt, client.crt, and client.key files from your FortiGate. These files are used for authentication.

Step 3: Import the Configuration File into OpenVPN Client

Open the OpenVPN client.
Click Import and select the configuration file you downloaded or created.
Enter your username and password when prompted.
Click Connect to establish the VPN connection.

Troubleshooting Common Issues

Sometimes, things don't go as planned. Here are some common issues and how to troubleshoot them:

Connection Refused:
- Make sure the FortiGate SSL VPN is enabled.
- Check that the firewall policy is configured correctly.
- Verify that the OpenVPN client is using the correct IP address and port number.
Authentication Failed:
- Double-check the username and password.
- Ensure that the user is a member of the VPN user group.
- Verify that the fortigate-ca.crt, client.crt, and client.key files are correct.
No Internet Access:
- Check the split tunneling settings. If split tunneling is enabled, make sure the destination network is configured correctly.
- Verify that the firewall policy allows traffic to the internet.

Security Considerations

Security is paramount when setting up a VPN. Here are some security considerations to keep in mind:

Use Strong Passwords: Always use strong, unique passwords for your VPN users.
Enable Multi-Factor Authentication (MFA): MFA adds an extra layer of security by requiring users to provide a second form of authentication, such as a code from their smartphone.
Keep Your FortiGate Firmware Up to Date: Fortinet regularly releases firmware updates to address security vulnerabilities. Make sure your FortiGate is running the latest firmware.
Monitor VPN Logs: Regularly monitor the VPN logs for suspicious activity.

Conclusion

Setting up a FortiGate SSL VPN with an OpenVPN client can seem daunting, but by following these steps, you can create a secure and reliable VPN connection. Remember to pay attention to the details, troubleshoot any issues that arise, and always prioritize security. Now you are able to configure Fortigate SSL VPN with OpenVPN client.

By following these instructions, you'll be able to establish a secure connection to your FortiGate SSL VPN using an OpenVPN client, giving you the flexibility and security you need for remote access. Keep in mind that network configurations can vary, so you might need to adapt these instructions to fit your specific setup. Always test your VPN thoroughly after making changes to ensure everything is working as expected. You should also be aware of the specific features related to Fortigate SSL VPN OpenVPN client.
