Hey guys! Thinking about squeezing an ITX build into your Phanteks Evolv X? You've come to the right place! The Phanteks Evolv X is a fantastic case, known for its sleek design, excellent airflow, and spacious interior. While it's primarily designed for ATX motherboards, with a little know-how and the right upgrade kit, you can absolutely rock an ITX setup in this beauty. This guide will walk you through everything you need to know about the Phanteks Evolv X ITX upgrade, from why you might want to do it, to the components you'll need, and how to get it all set up.

Why Go ITX in an Evolv X?

So, why would you want to put a smaller ITX motherboard in a case that's clearly built for larger formats? There are several compelling reasons:

• Aesthetics: Some builders prefer the clean, minimalist look of an ITX build with more empty space showcasing components. An ITX motherboard nestled in the larger Evolv X can create a striking visual contrast, emphasizing the case's spaciousness and your chosen components.
• Unique Builds: ITX builds in larger cases offer a unique aesthetic. You get the best of both worlds: the small footprint and visual appeal of ITX with the superior cooling and expansion options of a larger case like the Evolv X. This allows for creative layouts and the showcasing of high-end components in a less cramped environment.
• Flexibility: Maybe you already have an Evolv X and want to repurpose it for a smaller, more compact gaming or media center PC. Instead of buying a new case, the ITX upgrade kit lets you adapt your existing one. Plus, the extra space in the Evolv X allows for superior cable management and cooling solutions compared to smaller ITX-specific cases. You could even run a custom water-cooling loop without the space constraints typically associated with ITX builds.
• Cooling: ITX cases can sometimes be thermally constrained. The Evolv X offers significantly better airflow and space for larger coolers, preventing thermal throttling and ensuring stable performance, especially with high-end CPUs and GPUs. The Evolv X's robust cooling options, including support for multiple radiators and large air coolers, make it an ideal choice for housing a powerful ITX system that requires effective heat dissipation.
• Future-Proofing: The Evolv X's modular design and ample space mean that upgrading components down the line is easier. You won't be as limited by space constraints as you might be in a smaller ITX case. The generous interior of the Evolv X provides ample room for future upgrades, whether it's adding more storage, installing a more powerful GPU, or expanding your cooling setup. This makes it a more future-proof choice compared to smaller, more restrictive ITX cases.

What You'll Need

Alright, let's get down to the nitty-gritty. To successfully install an ITX motherboard in your Evolv X, you'll need a few key things:

1. Phanteks Evolv X ITX Upgrade Kit: This is the most important part! This kit usually includes a new motherboard tray specifically designed for ITX boards, along with the necessary standoffs and screws. Make sure you get the correct kit designed for the Evolv X, as other kits won't fit properly. This ensures proper alignment and stability of your ITX motherboard within the larger case.
2. ITX Motherboard: Obviously! Choose a board that fits your CPU socket and has the features you need, such as sufficient USB ports, M.2 slots, and connectivity options. Research compatibility and read reviews to ensure the board meets your requirements and performs well. Consider factors like VRM quality, BIOS features, and onboard audio when making your selection.
3. ITX-Compatible CPU Cooler: While the Evolv X has plenty of space for larger coolers, you'll still want to ensure compatibility with your chosen ITX motherboard. Some larger air coolers might overhang components, so check dimensions before you buy. Alternatively, consider a liquid cooler for optimal thermal performance. Ensure the cooler you choose fits within the Evolv X's dimensions and provides adequate cooling for your CPU, especially if you plan on overclocking.
4. Power Supply (PSU): The Evolv X can accommodate standard ATX PSUs, so you likely won't need to buy a new one unless you're upgrading from a smaller case. Just make sure it has enough wattage for your components. A modular PSU will help with cable management, which is always a plus in any build. Choose a PSU with sufficient wattage for your system's needs, and consider a modular design for easier cable management. This will help keep your build clean and improve airflow.
5. Other Components: Don't forget your CPU, RAM, GPU, storage drives (SSD, HDD), and any other peripherals you need. Ensure all components are compatible with your ITX motherboard and PSU. Double-check the specifications and requirements of each component to avoid any compatibility issues during the build process.

Installation: Step-by-Step

Okay, you've got all your parts. Let's get building! Remember to always ground yourself before working on computer components to avoid electrostatic discharge (ESD) damage.

1. Disassemble the Evolv X: Start by removing all the existing components from your Evolv X case. This includes the motherboard, standoffs, and any other parts that might be in the way. Keep the screws organized, as you'll need some of them later. Take your time and carefully disconnect all cables to avoid damaging any components.
2. Install the ITX Motherboard Tray: Remove the original ATX motherboard tray and replace it with the ITX-compatible tray from the upgrade kit. This usually involves unscrewing the old tray and screwing in the new one. Make sure the ITX tray is securely fastened to the case to provide a stable mounting platform for your motherboard. Align the tray properly and ensure all screws are tightened to prevent any movement or vibration.
3. Mount the ITX Motherboard: Place the ITX motherboard onto the new tray, aligning the mounting holes with the standoffs. Screw in the motherboard using the provided screws. Don't overtighten the screws, as this could damage the motherboard. Ensure the motherboard is securely mounted and doesn't wobble. Double-check that all standoffs are properly aligned and that the motherboard sits flush against the tray.
4. Install CPU, RAM, and Cooler: Install your CPU, RAM, and CPU cooler onto the ITX motherboard, following the manufacturer's instructions. This is usually easier to do before installing the motherboard into the case, as it gives you more room to work. Ensure the cooler is properly mounted and makes good contact with the CPU to ensure effective heat dissipation. Apply thermal paste correctly and securely fasten the cooler to the motherboard.
5. Connect Cables: Connect all the necessary cables to the motherboard, including the power supply cables, front panel connectors, USB headers, and SATA cables. Route the cables neatly to ensure good airflow and a clean appearance. Use cable ties or Velcro straps to manage the cables and keep them out of the way of fans and other components. Ensure all cables are securely connected to avoid any connectivity issues.
6. Install GPU and Storage: Install your GPU into the PCIe slot and connect your storage drives (SSD, HDD) to the SATA ports. Secure the GPU with screws to prevent it from moving during transportation. Connect the necessary power cables to the GPU and storage drives. Consider the placement of your storage drives to optimize airflow and cable management.
7. Test and Troubleshoot: Before closing up the case, power on your system and test that everything is working correctly. Check that the CPU, RAM, GPU, and storage drives are all recognized by the BIOS. If you encounter any issues, consult the motherboard manual or online resources for troubleshooting tips. Ensure all components are functioning properly before proceeding.
8. Cable Management: Now, take the time to manage your cables properly. Use zip ties, Velcro straps, or cable sleeves to bundle and route the cables neatly. This will improve airflow and make your build look much cleaner. Hide any excess cable length behind the motherboard tray or in other hidden areas of the case. Proper cable management is essential for optimal cooling and aesthetics.
9. Close It Up: Once you're satisfied that everything is working correctly and the cables are managed, close up the case and enjoy your new ITX build in the Phanteks Evolv X! Make sure all panels are securely attached and that the case is stable. Admire your handiwork and enjoy the performance and aesthetics of your new build.

Tips and Tricks

• Plan Your Build: Before you start buying parts, plan out your entire build. Consider the size of your components, the wattage of your power supply, and the airflow of your case. This will help you avoid any compatibility issues or bottlenecks. Research and select components that complement each other in terms of performance and compatibility. Create a detailed parts list and budget to stay organized.
• Cable Management is Key: Good cable management is essential for a clean and efficient build. Take the time to route and hide your cables properly. This will improve airflow and make your build look much more professional. Use cable ties, Velcro straps, or cable sleeves to manage your cables effectively. Plan your cable routing strategy before you start building.
• Consider Cooling: ITX builds can sometimes be thermally constrained, so it's important to choose a good CPU cooler and ensure adequate airflow in your case. Consider a liquid cooler for optimal thermal performance. Monitor your CPU and GPU temperatures to ensure they are within safe limits. Adjust fan speeds and airflow accordingly to maintain optimal cooling.
• Read the Manuals: Always read the manuals for your motherboard, case, and other components before you start building. This will help you avoid any mistakes and ensure that you are installing everything correctly. The manuals contain valuable information about component compatibility, installation procedures, and troubleshooting tips.
• Take Your Time: Building a PC can be a complex process, so don't rush it. Take your time and be careful when handling the components. Double-check your work and make sure everything is connected properly before you power on the system. Rushing the process can lead to mistakes and damage to components.

Conclusion

So there you have it! Converting your Phanteks Evolv X to an ITX build is totally doable with the right upgrade kit and a little patience. You'll get a unique-looking system with great cooling potential. Have fun building, and happy gaming! If you've got any questions or cool build pics, share them in the comments below! We love seeing what you guys come up with. Remember, the key to a successful ITX build in the Evolv X is careful planning, attention to detail, and a bit of creativity. Enjoy the process and the awesome results!
